Verilog 打砖块游戏

代码来源：https://www.fpga4fun.com/BreakoutGame.html

项目结构

从网站上下载下来的代码很简洁，只有四个文件：

1
.
2
├── breakout_playfield.v
3
├── breakout_videogen.v
4
├── breakout.ucf
5
└── breakout.v
6

7
1 directory, 4 files

其中：

breakout.v: 硬件接口层（VGA、LED、音频）
breakout_videogen.v: 显示控制层（时序、渲染）
breakout_playfield.v: 游戏逻辑层（碰撞、状态）

而 breakout.ucf 则是约束文件，它负责引脚映射。

`breakout.v`

从 breakout.v 开始。

1
// (c) KNJN LLC 2024 for fpga4fun.com
2

3
////////////////////////////////////////////////////////////////////////
4
module breakout(
5
    input clk,
6
    output VGA_HS, VGA_VS, VGA_R, VGA_G, VGA_B,
7
    output [1:0] LED,
8
    output audioR, audioL
9
);
10

11
wire [9:0] PaddleX;  // paddle position
12

13
// if you have a way to control the paddle, make sure to update PaddleX here
14
assign PaddleX = 10'd900;  // othersise this line puts the paddle off-screen to run the game in demo mode
15

16
wire DrawArea, hSync, vSync, red, green, blue, Collision, BrickHit;
17
breakout_videogen myVideoGen(
18
    .clk(clk),
19
    .PaddleX(PaddleX),
20
    .DrawArea(DrawArea), .hSync(hSync), .vSync(vSync), .red(red), .green(green), .blue(blue),
21
    .Collision(Collision), .BrickHit(BrickHit)
22
);
23

24
assign VGA_R = DrawArea & red;
25
assign VGA_G = DrawArea & green;
26
assign VGA_B = DrawArea & blue;
27
assign VGA_HS = ~hSync;
28
assign VGA_VS = ~vSync;
29
assign LED = {BrickHit, Collision & ~BrickHit};
30

31
reg [15:0] audio;  always @(posedge clk)  audio <= audio + Collision + BrickHit;
32
assign audioR = audio[15];
33
assign audioL = audio[15];
34
endmodule

开头先是连接 VGA 输出信号（RGB、同步信号），然后处理球拍位置。虽然但是，这个球拍在这个程序里是一个写死的常量，如果有控制球拍的逻辑还要另外跟它信号连上。

然后和 breakout_videogen.v 有关的代码，和传视频信号有关的，放到后面再看。

`breakout_videogen.v`

1
// (c) KNJN LLC 2024 for fpga4fun.com
2

3
////////////////////////////////////////////////////////////////////////
4
module breakout_videogen(
5
 input clk,
6
 input [9:0] PaddleX,
7
 output reg DrawArea, hSync, vSync,
8
 output red, green, blue,
9
 output reg Collision, BrickHit
10
);
11

12
//localparam ballspeed = 2; // ball moves 4 pixels per frame
13
localparam ballspeed = 3; // ball moves 8 pixels per frame
14
reg [9:0] ballX = 100;  // initial ball position
15
reg [8:0] ballY = 300;
16
reg ball_dirX, ball_dirY;
17

18
////////////////////////////////////////////////////////////////////////
19
parameter hDrawArea = 640;
20
parameter hSyncPorch = 16;
21
parameter hSyncLen = 96;
22
parameter hFrameSize = 800;
23

24
parameter vDrawArea = 480;
25
parameter vSyncPorch = 10;
26
parameter vSyncLen = 2;
27
parameter vFrameSize = 525;
28

29
reg [9:0] CounterX;
30
reg [8:0] CounterY;
31
always @(posedge clk) CounterX <= (CounterX==hFrameSize-1) ? 10'd0 : CounterX+10'd1;
32
always @(posedge clk) if(CounterX==hFrameSize-1) CounterY <= (CounterY==vFrameSize-1) ? 9'd0 : CounterY+9'd1;
33
always @(posedge clk) DrawArea <= (CounterX<hDrawArea) & (CounterY<vDrawArea);
34
always @(posedge clk) hSync <= (CounterX>=hDrawArea+hSyncPorch) & (CounterX<hDrawArea+hSyncPorch+hSyncLen);
35
always @(posedge clk) vSync <= (CounterY>=vDrawArea+vSyncPorch) & (CounterY<vDrawArea+vSyncPorch+vSyncLen);
36

37
////////////////////////////////////////////////////////////////////////
38
wire DrawBall, DrawBorder, DrawPaddle, DrawBrick, BrickHit_now, BrickHit_acq;
39
reg RestoreBrickwall = 1'b1;
40
reg MoveBall;
41
breakout_playfield #(hDrawArea, vDrawArea) game(
42
 .clk(clk),
43
 .PaddleX(PaddleX),
44
 .CounterX(MoveBall ? ballX + {6'h00, {4{CounterX[0]}}} : CounterX),
45
 .CounterY(MoveBall ? ballY + {5'h00, {4{CounterX[1]}}} : CounterY),
46
 .ballX(ballX),
47
 .ballY(ballY),
48
 .DrawBall(DrawBall), .DrawBorder(DrawBorder), .DrawPaddle(DrawPaddle), .DrawBrick(DrawBrick),
49
 .BrickHit_now(BrickHit_now), .BrickHit_acq(BrickHit_acq), .RestoreBrickwall(RestoreBrickwall)
50
);
51

52
// we are going to update the ball position during offscreen timing
53
wire FrameTick = (CounterX==hFrameSize-1) & (CounterY==vDrawArea-1);
54
always @(posedge clk) MoveBall <= MoveBall ? ~&CounterX[ballspeed+2:0] : FrameTick;
55
wire BounceableOject = DrawBorder | DrawPaddle | DrawBrick;
56
reg [3:0] HBC;  always @(posedge clk) HBC <= {BounceableOject, HBC[3:1]};  // record the ball corners hits in HBC (HotBallCorner)
57
wire [15:0] updateDirX = 16'b01101101_10110110;  // and update the ball direction if needed
58
wire [15:0] updateDirY = 16'b01111001_10011110;
59
always @(posedge clk) if(MoveBall & CounterX[2:0]==3'h5 & updateDirX[HBC]) ball_dirX <= (~HBC[0] &  HBC[1]) | (~HBC[2] & HBC[3]);
60
always @(posedge clk) if(MoveBall & CounterX[2:0]==3'h5 & updateDirY[HBC]) ball_dirY <= (~HBC[0] & ~HBC[1]) | ( HBC[2] & HBC[3]);
61
always @(posedge clk) if(MoveBall & CounterX[2:0]==3'h7) ballX <= ballX + {{9{ball_dirX}}, 1'b1};  // and then the ball position
62
always @(posedge clk) if(MoveBall & CounterX[2:0]==3'h7) ballY <= ballY + {{8{ball_dirY}}, 1'b1};
63

64
// then get stats on ball collisions and brick hits
65
reg [2:0] BHA;  always @(posedge clk) BHA <= {DrawBrick, BHA[2:1]};
66
assign BrickHit_now = MoveBall & CounterX[2] & BHA[0];
67
always @(posedge clk) if(FrameTick) BrickHit<=1'b0; else if(BrickHit_now) BrickHit<=1'b1;
68
reg [7:0] BrickHit_count=0;  always @(posedge clk) BrickHit_count <= RestoreBrickwall ? 8'h00 : BrickHit_count + BrickHit_acq;
69
always @(posedge clk) RestoreBrickwall <= RestoreBrickwall ? ~FrameTick : (BrickHit_count==19*7) & ballY[8];
70
always @(posedge clk) if(FrameTick) Collision<=1'b0; else if(MoveBall & CounterX[2] & HBC[1]) Collision<=1'b1;
71

72
wire DrawAll = DrawBall | DrawBorder | DrawPaddle | DrawBrick;
73
assign red = DrawBrick;
74
assign green = DrawAll;
75
assign blue = DrawAll;
76
endmodule

查了一下，breakout_videogen.v 实现标准 VGA 640x480@60Hz 时序，即以下规范：

水平时序：
- 可见区域：640 像素
- 前肩（Front Porch）：16 像素
- 同步脉冲：96 像素
- 后肩（Back Porch）：48 像素
- 总计：800 像素
垂直时序：
- 可见区域：480 行
- 前肩：10 行
- 同步脉冲：2 行
- 后肩：33 行
- 总计：525 行

因为老 CRT 显示器是用电子束从左到右、从上到下逐行扫描的，扫描完一行需要时间回到下一行开始需要返回时间，所以需要同步脉冲来调整时序。好吧这个不重要。

接着通过两个计数器生成像素坐标：

CounterX: 水平像素计数（0-799），对应寄存器长度是 $2^10-1$ ，大于 $800$ ；
CounterY: 垂直行计数（0-524），对应寄存器长度是 $2^9-1$ ，实际上不够存，不知道这里为什么这么设计；
DrawArea: 标识当前像素是否在可显示区域内。

总计 $800×525 = 420,000$ 个时钟周期完成一帧。

球的运动用 X 和 Y 两个分解方向表示，运动状态机由 MoveBall 控制。MoveBall 的逻辑是：当为真时检查~&CounterX[ballspeed+2:0]（不全为 1 时继续），当为假时等待 FrameTick 重新启动，这里 +2 是控制球移动频率。也就是说：

当 MoveBall=0 时，等待 FrameTick（帧结束）信号来启动移动
当 MoveBall=1 时，检查 ~&CounterX[ballspeed+2:0]，当 CounterX 的低 (ballspeed+3) 位不全为 1 时继续移动。ballspeed=3 时，检查 CounterX[5:0]，意味着每 64 个时钟周期球移动一次。

碰撞检测通过 HBC（Hot Ball Corner）机制实现，HBC <= {BounceableOject, HBC[3:1]}进行右移操作，记录连续 4 个时钟周期的碰撞历史状态。系统使用两个 16 位查找表updateDirX和updateDirY，根据 HBC 的 4 位值索引决定是否更新球的方向，在时钟周期 5 更新方向，时钟周期 7 更新位置，避免了复杂的碰撞计算。

砖块碰撞通过 BHA 记录砖块碰撞历史，BrickHit_now检测当前击中状态，BrickHit作为帧级标志在每帧开始清零、有碰撞时置 1。BrickHit_count计数器跟踪总击中砖块数（19×7=133 块），当全部击中且球到达顶部时RestoreBrickwall重置砖墙。Collision标志类似地在每帧清零，球移动时检测到碰撞则置 1。

`breakout_playfield.v`

1
// (c) KNJN LLC 2024 for fpga4fun.com
2

3
/////////////////////////////////////////////////////////////////
4
module breakout_playfield(
5
    input clk,
6
    input [9:0] CounterX, ballX, PaddleX,
7
    input [8:0] CounterY, ballY,
8

9
    output reg DrawBall, DrawBorder, DrawPaddle,
10
    output DrawBrick,
11

12
    input BrickHit_now, RestoreBrickwall,
13
    output BrickHit_acq
14
);
15

16
parameter hDrawArea = 640;
17
parameter vDrawArea = 480;
18

19
always @(posedge clk) DrawBall <= (CounterX>=ballX) && (CounterX<ballX+10'd16) && (CounterY>=ballY) && (CounterY<ballY+9'd16);
20
always @(posedge clk) DrawBorder <= (CounterX[9:2]==0) || (CounterX[9:2]==hDrawArea/4-1) || (CounterY[8:2]==0) || (CounterY[8:2]==vDrawArea/4-1);
21
always @(posedge clk) DrawPaddle <= (CounterX>=PaddleX) && (CounterX<=PaddleX+10'd64) && (CounterY>=vDrawArea-9'd46) && (CounterY<vDrawArea-9'd30);
22

23
// the brickwall starts at coordinates (16,48)
24
wire [9:0] BrickXo = CounterX-10'd16;        wire [4:0] BrickX_H = BrickXo[9:5];        wire [4:0] BrickX_L = BrickXo[4:0];
25
wire [8:0] BrickYo = CounterY- 9'd48;        wire [4:0] BrickY_H = BrickYo[8:4];        wire [3:0] BrickY_L = BrickYo[3:0];
26
wire [9:0] BrickA = {BrickY_H, BrickX_H};  // and is organized as a 32 x 32 matrix
27
reg [1023:0] RAMbrickwall;  // in this blockram
28

29
reg BrickPresent, BrickHit_nowR;
30
always @(posedge clk)
31
begin
32
    if(BrickHit_now | RestoreBrickwall) RAMbrickwall[BrickA] <= RestoreBrickwall ? BrickX_H<19 & BrickY_H<7 : 1'b0;  // 19 x 7 brickwall
33
    BrickPresent <= RAMbrickwall[BrickA];
34
    BrickHit_nowR <= BrickHit_now;
35
end
36
assign BrickHit_acq = BrickPresent & BrickHit_nowR;
37

38
reg BrickBody;  always @(posedge clk) BrickBody <= |BrickY_L[3:1] && |BrickX_L[4:1];  // leave two pixels between each brick
39
assign DrawBrick = BrickPresent & BrickBody;
40
endmodule

这个模块负责游戏场景中各个对象的绘制判断。球的绘制区域是 16×16 像素，通过比较当前扫描位置与球坐标确定；边框绘制使用位移操作CounterX[9:2]和CounterY[8:2]，实际上是将坐标除以 4，在 640×480 显示区域的边缘绘制 4 像素宽的边框；挡板绘制在屏幕底部，宽度 64 像素，位置在距离底部 30-46 像素的区域，跟随 PaddleX 水平移动。所有这些绘制判断都通过比较当前扫描坐标与对象坐标范围来实现。

砖墙从坐标 (16,48) 开始，通过坐标变换BrickXo和BrickYo计算相对位置，然后分别提取高位和低位部分。BrickX_H和BrickY_H作为 32×32 矩阵的索引，组成 10 位地址BrickA访问 1024 位的块 RAMRAMbrickwall。砖块的实际排列是 19×7 的矩阵，在RestoreBrickwall信号时恢复，在BrickHit_now信号时清除对应位置的砖块。BrickBody通过检查坐标的低位部分BrickY_L[3:1]和BrickX_L[4:1]是否非零来在砖块间留出 2 像素的间隙，最终的DrawBrick信号需要同时满足砖块存在和在砖块主体区域的条件。BrickHit_acq信号在砖块存在且检测到击中时产生，用于游戏逻辑的砖块计数。
